Description
- HIPERFACE®
- Synchronous Serial Interface SSI
- Siemens DRIVE-CLiQ
- FANUC
Technical data
HIPERFACE® (optional: HF)
HIPERFACE® is a registered trademark of SICK STEGMANN GmbH.
HIPERFACE® stands for high performance interface and is a hybrid interface. It is composed of the analog process data channel on which the sinusoidal and cosine signals (analog option I1) are transferred differentially and almost instantly, as well as the bidirectional parameter channel for transmitting the absolute position and other different parameters.
Furthermore, an electronic nameplate for identification and for storing drive-relevant information in the motor feedback is available. IMS-A with HIPERFACE® interface is the optimum solution for REXROTH drive systems.
| Option | HF | |
| Power supply | 7 V to ... 28 V (at connector) | |
| Current consumption | 7 V, 250 mA | |
| Max. measuring speed | m/s | 5 |
| Resolution of the digital interface (µm) | µm | 1.25 |
SSI – Synchronous Serial Interface (options: S1, S2, S3, S4)
With the synchronous serial interface (SSI), the absolute position information is transferred to higher-level evaluation electronics via serial data transmission. Parallel to the serial data transmission, the incremental sinusoidal and cosine signals (analog option I1) are also available for enhancing the control performance. For the different requirements of the evaluation electronics in terms of the position resolution, the following SSI configurations can be chosen:
| Option | S1 | S2 | S3 | S4 | |
| Kodierung | Binary | Gray | |||
| Bitanzahl (Positionen) | 22 | 25 | 27 | 28 | |
| Parität | straight | none | |||
| Fehlerbit | Yes | no | |||
| Warnbit | Yes | no | |||
| Auflösung der digitalen Schnittstelle | µm | 10 | 1 | 0.25 | 0.125 |
| Max. clock frequency | MHz | 2 | |||
| Power supply | 4.75 V to ... 28 V (at connector) | ||||
| Current consumption | 5 V, 300 mA | ||||
| Max. measuring speed | m/s | 5 | |||
DRIVE-CLiQ (Option: DQ)
DRIVE-CLiQ is a protected trademark of Siemens.
This system interface is used for connecting measuring systems to the drive components from Siemens. IMS-A with DRIVE-CLiQ interface enables easier start-up, as the interface has an electronic nameplate. This contains IMS-A-specific data, which enables error-free configuration of the drive system during start-up.
| Option | DQ | |
| Power supply | 13,2 V to ... 30,8 V (at connector) | |
| Current consumption | 110 mA maximum | |
| Max. measuring speed | m/s | 5 |
| Resolution of the digital interface (µm) | µm | 0.025 |
FANUC (Option: FN)
IMS-A with serial FANUC interface αi offers robust, reliable, and purely serial communication for high performance tooling machines with FANUC control units.
| Option | FN | |
| Power supply | 4,6 V to ... 12,6 V (at connector) | |
| Current consumption | 350 mA maximal | |
| Max. measuring speed | m/s | 5 |
| Resolution of the digital interface (µm) | µm | 0.025 |
Downloads
 | Integrated Measuring System IMS for Ball and Roller Rail systems / Instructions for electrical interfaces / only PDF Manual | R320103166_EN | 2017-10-01 | English | PDF | 2.4MB Product Groups: Integrated measuring systems |
| Integrated Measuring System IMS for Ball and Roller Rail Systems Manual | R320103262_EN | 2020-07-01 | English | PDF | 1.8MB Product Groups: Integrated measuring systems |
| Catalog Integrated Measuring System IMS for Ball and Roller Rail Systems Catalog | R999000487 | 2020-06-01 | English | PDF | 2.7MB Product Groups: Ball Rail Systems, Roller Rail Systems, Integrated measuring systems Catalog Integrated Measuring System IMS for Ball and Roller Rail Systems |
